Magnetic Turbine Solutions

Explore our cutting-edge technology for converting magnetic repulsion force into rotational kinetic energy.

Radially oriented ring magnet
Radial ring magnet field
The production line will consist of 3D metal additive technology.
Effect of magnetic force on the opposing regime
Ring Magnet

Presentation of the action of photons in the magnetic field of a ring magnet at reduced speeds.

Products » Neodymium Ring Magnets

RZ0Y0X0 RZ0Y0X0

Description Technical Downloads Dimensions: 3" od x 2" id x 1" thick Tolerances: ±0.004" x ±0.004" x ±0.004" Material: NdFeB, Grade N42 Plating/Coating: Ni-Cu-Ni (Nickel) Magnetization Direction: Axial (Poles on Flat Ends) Weight: 17.0 oz. (483 g) Pull Force, Case 1: 253.3 lbs Pull Force, Case 2: 253.3 lbs Max Operating Temp: 176ºF (80ºC) Brmax: 13,200 Gauss BHmax: 42 MGOe

These large rings are very strong and good for a variety of applications and experiments. They must be handled with care as they will pinch fingers and probably break if they are allowed to slam together. These are currently the largest rings that we stock.

Price: $100.40 x1= 100.40

Magnetic field interaction of pair magnets

We developed the technology for producing a permanent magnet turbine as a magnetic mechanical device designed to convert the repulsion force of paired permanent magnets (NdFeB) into rotational kinetic energy.
Based on the technological platform and the properties of permanent magnets, and utilizing them effectively to maximize mechanical energy, we designed and built the Magnet Turbine prototypes Alpha and Beta 1&2 for testing purposes.
Technology

Innovative technology for magnetic turbine energy production.

Energy
